SOLAR MPPT PCU : ROVER 3036 - 36V

SOLAR MPPT PCU : ROVER 3036 - 36V

-5%₹39,500.00

M.R.P. :

₹41,900.00

ASHAPOWER SOLAR MPPT PCU - ROVER-3000-36V is a Premium Quality High Power Solar energy extractor for your home / office having a connected load of 2400Watts.It can be loaded with Fan, LED lights, Iron box, induction cooker, Inverter AC, Computer, LED TV, Washing machine , Refrigerator, Laser printer, and an Induction motor pump when used with 2400 watts solar PV panels and 36V / 200Ah batteries. The integration of a highly efficient MPPT SCC (165 Voc / 60 AMP / 2500 Wp), 2400W DSP pure sine wave inverter, high power grid charger and the low energy consumption makes it unique in its class.

Key Features

  • High Grade CRGO Laminated Pure Copper Transformer
  • 0.8 Constant Output Power Factor 3000VA = 2400W Max. O/P load)
  • No Load DC Current < 0.7A + - 0.3A
  • User configurable solar priority and grid priority charging modes
  • Customer control over grid charging ON/OFF
  • Large 4 Line multifunctional LCD front panel display
  • Soft front panel all function control switches. No Rocker switches behind the device
  • PV Panel load 2500Wp if Voc 165V / 3000Wp if Voc < 120V
  • Intelligent true multi stage smart solar and grid charging (Bulk, Absorption, Float)
  • Battery grid charging even at low grid voltage
  • High over load and surge load handling capacity
  • All type battery compatibility Including LiFePO4 with BMS
  • Unique ZMPT based isolated grid sensing to reduce lighning hazards
  • Forced grid to solar mode shifting facility
  • Zero grid power consumption on Idle Stage
  • Constant noise free DSP pure sine wave output
  • MCB short circuit protection for grid power
  • Blade Fuse protection for Internal Components
  • Over load, surge and short circuit protection

Specifications

PV INPUT

Max. Applicable PV Panel VOC165 V
Max. Applicable PV Panel Load on MPPT2500 Wp

OUTPUT

Humidity0 to 90% RH (No dew)
Operating temperature- 20 degree to 65 degree C
Storage temperature- 30 degree to 80 degree C
Max. output power2400 W
Maximum MPPT tracking efficiency98.9 %
No load battery Power Consumption0.7 AMP + - 0.3
Maximum grid battery charging current4 AMP TO 20 AMP(configurable)
Nominal Battery Voltage36 V DC
Maximum solar Charging Current60 Amps (configurable)

SPECIAL FEATURES

Standby grid Power ConsumptionZero at idle stage
Overload Protection From PV PanelYES
Over Charge Protection from grid and solarYES
Panel Reverse Polarity ProtectionYES
Battery Reverse Polarity ProtectionOPTIONAL

PHYSICAL

Display4 line LC Display
Connectors6 Way Input / Output Terminal block
Net Weight (Kgs) / Gross Weight (Kgs)24.7 / 26.5
Dimensions – L x W x H (cm)50.0 x 19.7 x 33.5

Downloads

36V SOLAR MPPT PCU ROVER-3000-36V.pdf

6.0 MB
