HOME UPS LANDER 2524 - 24V

HOME UPS LANDER 2524 - 24V

-10%₹21,500.00

M.R.P. :

₹23,900.00

ASHAPOWER HOME UPS - LANDER 2500-24V is a Premium Quality High power INVERTER / UPS for your home / office having a connected load of 2000 Watts. It can be loaded with Fans, LED lights, Iron box, Computer, normal Washing Machine, Inverter fridge, TV, Laser printer, and a low HP induction motor pump when used with 24V X 200 Ah batteries. It can be easily converted to a solar inverter using ASHAPOWER Solar MPPT Charge controller (SMU). A highly Efficient Pure Copper Transformer with high grade lamination, Smart Pure DSP sine wave inverter technology, high performance with low energy consumption and easy customer control over system functions makes it unique in its class.

Key Features

  • Pure Copper Transformer with High Grade Lamination
  • No Load DC Current Less than 0.7A +/- 0.3
  • User configurable Grid Charging Current up to 20 Amp
  • Customer Control Over AC Mains (grid) Charging ON/OFF
  • 70 Micron High Grade PCB
  • Battery Charging on Low Grid Voltage
  • Large 4 line Multi Functional LCD Display
  • Zero Grid Power Consumption on Idle Stage
  • High Over Load and Surge Load Handling Capacity
  • Unique ZMPT Based Isolated Grid Power Sensing
  • Forced Grid to Solar Mode Shifting Facility
  • Soft Front Panel all Function Control Switches - No Rocker Switches Behind the Device
  • Intelligent Multi Stage Smart Charging (Bulk, Absorption, Float,)
  • Best In Class External Surge /Lightning Protection
  • Compatible to all Types of Batteries Including LiFePo4 With BMS
  • Noise Free Pure DSP Sine Wave Output
  • MCB Short Circuit Protection for Grid Power
  • Blade Fuse Protection for Internal Components

Specifications

PHYSICAL

Connectors4 Way Input / Output Terminal block
Net Weight (Kgs) / Gross Weight (Kgs23.5 Kgs / 24.5 Kg
Dimensions – L x W x H (cm)44 x 20 x 34
Display4 line LC Display

SPECIAL FEATURES

Battery Reverse Polarity ProtectionOPTIONAL
Over Charge ProtectionYES
Standby grid Power ConsumptionZero at idle stage

OUTPUT

Nominal Battery Voltage24V DC
Humidity0 to 90% RH (No dew)
Operating temperature- 20 degree to 65 degree C
Storage temperature-30 degree to 80 degree C
No load battery Power Consumption0.7AMP + - 0.3
Maximum grid battery charging current4 AMP TO 20AMP

Downloads

24V- HOME UPS LANDER-2500-24V.pdf

4.4 MB
