180V-60A - (650Voc)

180V-60A - (650Voc)

-7%₹47,298.00

M.R.P. :

₹51,000.00

This 180V - 60A 3Ph IGBT Based Solar MPPT Charge Controller is a heavy duty device for Home/Industrial application. This MPPT based Solar Management Unit(SMU) is custom made as per your requirement where you can connect more no. of solar panels in series for off-grid projects ranging up to 13000 Watts. The 650V Voc helps you connect an existing solar plant with more modules in series without changing the PV panel grouping!!!

Key Features

  • High Voc and PV Panel Input Capacity.
  • IGBT Based Heavy Duty Hardware.
  • 4 stage smart charging for prolonged battery life (Bulk - Absorption - Float - Equalization).
  • Programmable Initial limited ampere battery charging facility.
  • dsPIC33EP family micro controller based devices.
  • PV panel reverse polarity protection.

Specifications

SPECIAL FEATURES

Panel Reverse Polarity ProtectionYES
Over Charge ProtectionYES
Battery Reverse Polarity ProtectionOPTIONAL
Overload ProtectionYES

PHYSICAL

Dimensions - LxWxH (mm)560 x 305 x 380
Connector6way - 50A
Net Weight (Kgs)28Kgs
Display4 Line Display

PV INPUT

Max PV Array Open Circuit Voltage (Voc)650V
Max PV Array Watts Applicable13000Wp

OUTPUT

Nominal Battery Voltage180V
Maximum Tracking Efficiency99%
Maximum Charging Current60A
Standby Power Consumption2W
